General purpose 'push-to-on button', self latch on push button. Single Pole Single Throw (SPST), normally open type. Press to connect and it will latch on itself. To disconnect, press the button to release.
Features and Spec
What's in the box?
1 x Round Panel Mount Latch Push Button (Red)
Features and Spec
- Normally Open (NO) type
- Contact rating :125VAC 3A
- Switch type: Push and lock
- Weight: 10g
- Material: Plastic (body and button)
- Button color: Red
- Pitch : 3mm
- Thread diameter: 12mm
- Button diameter: 9mm
- Height: 25mm (body height excluding terminal)
What's in the box?
1 x Round Panel Mount Latch Push Button (Red)
- Availability: 17 In Stock
- Model: 12mm red latch button
-
